Define the required fields of Service
Pre-defined Web UI’s Chart and Illustration:
Chart Illustration
Any Service
TCP Service, For example： FTP, FINGER, HTTP, HTTPS ,
IMAP, SMTP, POP3, ANY, AOL, BGP, GOPHER, Inter Locator,
IRC, L2TP, LDAP, NetMeeting, NNTP, PPTP, Real Media,
RLOGIN, SSH, TCP ANY, TELNET, VDO Live, WAIS,
WINFRAME, X-WINDOWS, …etc.
UDP Service, For example：IKE, DNS, NTP, IRC, RIP, SNMP,
SYSLOG, TALK, TFTP, UDP-ANY, UUCP,…etc.
ICMP Service, Foe example：PING, TRACEROUTE…etc.
New Service Name:
The System Manager can name the custom service.
Protocol:
The protocol type to be used in connection for device, such as TCP and UDP mode
Client Port:
The port number of network card of clients. (The range is 1024~65535, suggest to
use the default range)
Server Port:
The port number of custom service
