We set up two Service examples in this chapter:

No Suitable

Situation

Example

Ex1

Custom

Allow external user to communicate with internal

user by VoIP through policy. (VoIP Port: TCP 1720,

TCP 15325-15333, UDP 15325-15333)

Ex2

Group

Setting service group and restrict the specific users

only can access to service resource that provided by

this group through policy. (Group: HTTP, POP3,

SMTP, DNS)
