We set up two Alarm examples in the chapter:

No. Suitable

Situation

Example

Ex 1

Internal

Alarm

To record the DDoS attack alarm from internal PC

Ex 2

External

Alarm

To record the attack alarm about Hacker attacks the

SG-1000 and Intranet
