We set up four LOG examples in the chapter:

No. Suitable

Situation

Example

Ex 1

Traffic Log

To detect the information and Protocol port that users

use to access to Internet or Intranet by SG-1000.

Ex 2

Event Log

To record the detailed management events (such as

Interface and event description of SG-1000) of the

Administrator

Ex 3

Connection

Log

To detect event description of WAN Connection

Ex 4

Log Backup

To save or receive the records that sent by the SG-

1000
