Icom IC-P7A [25/96] Selecting a call channel
![Icom IC-P7A [25/96] Selecting a call channel](/views2/1074434/page25/bg19.png)
12
3
FREQUENCY AND CHANNEL SETTING
3
■ Selecting a memory channel
qPush [V/M] (
SKIP
•
S
.
MW
) momentarily to select memory
mode.
•“ ” appears when a memory channel is selected.
wRotate [DIAL] to select the desired memory channel.
• Only programmed memory channels can be selected.
• While pushing and holding [FUNC], rotate [DIAL] to select a
memory channel in 10 channel steps, blank channels can be se-
lected in this case.
■ Selecting a call channel
qPush [CALL] (
MODE
•
SCAN
) momentarily to select a call
channel.
wRotate [DIAL] to select the desired call channel.
ePush [CALL] (
MODE
•
SCAN
) or [V/M] (
SKIP
•
S
.
MW
) momen-
tarily to return to the previously selected mode.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S KI P
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S KI P
MR
5
1
9
144 MHz band 440 MHz band
• Call channel example (depends on version)
SCAN
S.MW
SET
SCAN
[DIAL]
SCAN
S.MW
SET
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S KI P
MR
5
1
9
[DIAL]
[DIAL] changes the mem-
ory channel.
S.MW
Push Push and hold Dual operation
