iii
SUPPLIED ACCESSORIES
qBattery pack (BP-243) ………………………………………1
wBattery charger (BC-164) …………………………………1
eAntenna ………………………………………………………1
rHandstrap ……………………………………………………1
tAC adapter* (BC-145LA/LE/LV) ……………………………1
(The shape of the BC-145LA, BC-145LE and BC-145LV are differ-
ent.)
*Depending on versions. Not supplied with some versions.
qw er
t
TABLE OF CONTENTS
FOREWORD ............................................................................................. i
IMPORTANT ............................................................................................. i
EXPLICIT DEFINITIONS .......................................................................... i
PRECAUTION .......................................................................................... ii
SUPPLIED ACCESSORIES .................................................................... iii
TABLE OF CONTENTS ........................................................................... iii
QUICK REFERENCE GUIDE ........................................................... I–VIII
■ Preparation........................................................................................ I
■ Your first contact.............................................................................. III
■ Repeater operation .......................................................................... V
■ Memory programming..................................................................... VI
■ Programmed scan operation.......................................................... VII
1PANEL DESCRIPTION ................................................................... 1–4
■ Front, top and side panels ............................................................... 1
■ Function display .............................................................................. 3
2BATTERY CHARGING ................................................................... 5–8
■ Caution............................................................................................. 5
■ Battery installation............................................................................ 7
■ Battery charging ............................................................................... 8
3 FREQUENCY AND CHANNEL SETTING .................................... 9–12
■ VFO and memory channels.............................................................. 9
■ Operating band selection ................................................................. 9
■ Setting a frequency......................................................................... 11
■ Setting a tuning step....................................................................... 11
■ Selecting a memory channel.......................................................... 12
■ Selecting a call channel.................................................................. 12
4 BASIC OPERATION ................................................................... 13–18
■ Receiving........................................................................................ 13
■ Setting audio volume...................................................................... 13
■ Squelch level setting ...................................................................... 14
■ Operating mode selection .............................................................. 14
■ Monitor function.............................................................................. 15
■ Attenuator function ......................................................................... 15
