75
SPECIFICATIONS
14
■ Transceiver
D General
• Frequency coverage : (unit: MHz)
*
1
Guaranteed 440–450 MHz only, *
2
Guaranteed 144–148 MHz only
*
3
Guaranteed 430–440 MHz only
• Mode : FM, AM (Rx only), WFM (Rx only)
• No. of memory channels : 1250 (incl. 50 scan edges, 200 auto
memory write channels)
• No. of call channels : 2 channels
• Usable temp. range : –10°C to +60°C; +14°F to +140°F
•Tuning steps : 5, 6.25, 8.33, 9, 10, 12.5, 15, 20, 25,
30, 50, 100 and 200 kHz
•Frequency stability : ±6 ppm (–10°C to +60°C;+14°F to +140°F)
• Power supply : Specified battery pack (3.7 V DC)
• Current drain
(at 3.7 V DC) :
Tx High 144, 440 MHz Less than 1.5 A
Tx Low 144 MHz 0.4 A (approx.)
440 MHz 0.5 A (approx.)
Rx max. power Less than 150 mA
standby 80 mA (approx.)
• Antenna connector : SMA (50 Ω)
•
External MIC/SP connector
: 4-conductor 3.5(d) mm;
1
⁄8˝
8 Ω(SP)/2 kΩ(MIC)
• Dimensions : 47(W)×81(H)×28(D) mm;
(projections not included) 1
27
⁄32(W)×3
3
⁄16(H)×1
3
⁄32(D) in
•Weight (approx.) : 160 g; 5.64 oz
(with antenna and BP-243)
D Receiver
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st 46.35 MHz (FM/AM)
14.85 MHz (WFM)
2nd 450 kHz
• Sensitivity : (except spurious points)
FM (at 12 dB SINAD)
30.000–89.995 MHz Less than 0.45 µV
90.000–143.995 MHz Less than 0.2 µV
144.000–147.995 MHz Less than 0.18 µV
148.000–179.995 MHz Less than 0.2 µV
350.000–470.000 MHz 0.18 µV (typical)
(430.000–450.000 MHz Less than 0.18 µV)
600.000–939.990 MHz Less than 1.4 µV
940.000–999.990 MHz Less than 2.5 µV
U.S.A
Canada
Australia
Korea
Taiwan
General
Transmit
144–148, 430–450*
1
144–148, 430–450*
1
144–148, 420–450*
3
144–146, 430–440
144–146, 430–432
136–173.995*
2
,
400–478.995*
3
Receive
0.495–821.990,
*
1,
*
2
851–866.990,*
1,
*
2
896–999.990*
1,
*
2
0.495–999.990*
1,
*
2
0.495–999.990*
2,
*
3
144–146, 430–440
144–146, 430–432
0.495–999.990
*
2,
*
3
All stated specifications are subject to change without notice or obligation.
