Icom IC-P7A [91/96] Options
![Icom IC-P7A [91/96] Options](/views2/1074434/page91/bg5b.png)
78
15
OPTIONS
15
DD
HM-153
EARPHONE MICROPHONE
An optional OPC-782 is required for connection.
DD
HM-153P
EARPHONE MICROPHONE
Connects to the IC-P7A directly (without the OPC-782).
SCAN
SET
S
.M
W
Microphone
HM-153P
[MIC/SP]
cap
NOTE: Connect the HM-153P after removing
the [MIC/SP] cap (MIC/SP jack cover).
Keep the [MIC/SP] cap attached when jack
are not in use to keep the contact clean.
SCAN
SET
S
.M
W
Microphone
OPC-782
HM-153
Speaker/MIC
connector
[MIC/SP]
cap
NOTE: Connect the OPC-782 after removing
the [MIC/SP] cap (MIC/SP jack cover).
Keep the [MIC/SP] cap attached when jack
are not in use to keep the contact clean.
