18
4
BASIC OPERATION
4
■ [DIAL] function assignment
The [DIAL] control can be used as an audio volume control
instead of [
YY
]/[
ZZ
] keys to suit your preference. However,
while [DIAL] functions as an audio volume, [
YY
]/[
ZZ
] keys func-
tion as tuning controls.
➥
While pushing and holding [FUNC], push [
YY
]/[
ZZ
] to toggle
the [DIAL] function between tuning dial and audio volume.
• “VOL” appears when [DIAL] functions as an audio volume.
• [DIAL] and [
YY
]/[
ZZ
] functions
SCAN
S.MW
SET
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL
VOL
PRIO P SKIP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
Appears
or
■ Lock function
To prevent accidental frequency changes and unnecessary
function activation, use the lock function.
➥ While pushing and holding [FUNC], push and hold
[BAND] (
TS
•
LOCK
) for 1 sec. to turn the lock function ON
and OFF.
•“L” appears while the lock function is active.
• [SQL] (
ATT
•
SET
)
and [
YY
]/[
ZZ
] can be used while the lock function
is in use in default setting. Either or both [SQL] (
ATT
•
SET
) and
[
YY
]/[
ZZ
] keys may also be locked in set mode. (p. 56)
SCAN
S.MW
SET
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
Appears
No “VOL” indication “VOL” appears
Frequency, Memory channel,
Audio volume set
[DIAL]
Squelch level, Scanning Set mode condition set
direction, Set mode item
and condition set
Audio volume set
Frequency, Memory channel,
[
YY
]/[
ZZ
] Squelch level, Scanning
direction, Set mode item
