Icom IC-P7A [48/96] Full band programmed scan
![Icom IC-P7A [48/96] Full band programmed scan](/views2/1074434/page48/bg30.png)
qSelect VFO mode with [V/M] (
SKIP
•
S
.
MW
), if necessary.
• Select the desired frequency band with [BAND] (
TS
•
LOCK
), if de-
sired.
wSet the squelch to the point where noise is just muted.
ePush and hold [CALL] (
MODE
•
SCAN
) for 1 sec. to enter
scan type selection condition.
rRotate [DIAL] to select the desired scanning type.
• “ALL” for full scan; “BAND” for band scan, “PROGxx” for pro-
grammed scan (xx= 0 to 24; programmed scan edges numbers
only displayed)
tPush [CALL] (
MODE
•
SCAN
) again to start the scan
• Scan pauses when a signal is received.
• Rotate [DIAL] to change the scanning direction, or resumes
manually.
•To stop the scan, push [CALL] (
MODE
•
SCAN
).
About the scanning steps: The selected tuning step in
each frequency band (in VFO mode) is used during scan.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
• During full/band scan • During programmed scan
SCAN
S.MW
SET
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
• Full scan selection
• Band scan selection
• Programmed scan selection
Selectable between “ 0” to “24”
if programmed
SCAN
[DIAL]
■ Full/band/programmed scan
35
7
SCAN OPERATION
Push Push and hold Dual operation
