20
5
REPEATER OPERATION
5
When communicating through a repeater, the transmit fre-
quency is shifted from the receive frequency by the amount of
the offset frequency.
qWhile pushing and holding [FUNC], push and hold
[SQL] (
ATT
•
SET
) for 1 sec. to enter set mode.
wRotate [DIAL] to select “OFFSET.”
eWhile pushing and holding [FUNC], rotate [DIAL] to set the
desired offset frequency within 0.000–159.995 MHz range.
• The tuning step, selected in VFO mode, is used for setting.
rPush [SQL] (
ATT
•
SET
) to exit set mode.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIO P SKIP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S KIP
MR
5
1
9
After 1 sec.
Offset frequency item Setting indication
SCAN
S.MW
SET
[DIAL]
SET
■ Offset frequency
Push Push and hold Dual operation
