79
15
OPTIONS
DD
HM-128
EARPHONE MICROPHONE
An optional OPC-782 is required for connection.
DD
HM-131
SPEAKER MICROPHONE
An optional OPC-782 is required for connection.
DD
LC-161
CARRYING CASE
Helps protect the transceiver from scratches, etc.
Tension
release loop
LC-161
Transceiver
OPC-782
NOTE: When using as below illustration,
tension release loop protects the [MIC/SP]
connector from being damaged by cable
stress or vibration
e
w
q
HM-131
HM-128
