PRIORITY WATCH
DD
VFO scan watch
qPush [V/M] (
SKIP
•
S
.
MW
) to enter memory mode, then rotate
[DIAL] to select the memory channel.
wPush and hold [CALL] (
MODE
•
SCAN
) for 1 sec. to enter
scan type selection condition to select the scan type, then
push [CALL] (
MODE
•
SCAN
) again to start memory/bank
scan, if desired.
When scanning memory/bank channels:
Starts memory/bank scan first. Memory/bank scan can-
not be started after VFO scan is started.
eWhile pushing and holding [FUNC], push and hold
[SQL] (
ATT
•
SET
) for 1 sec. to enter set mode.
rRotate [DIAL] to select “PRIO.”
tWhile pushing and holding [FUNC], rotate [DIAL] to turn
the priority watch ON.
• Select “BELL” if the priority beep function is necessary.
yPush [SQL] (
ATT
•
SET
) to exit set mode and start the watch.
• “PRIO” indicator appears.
uPush [CALL] (
MODE
•
SCAN
) for 1 sec. to enter scan type se-
lection condition.
iRotate [DIAL] to select the desired scan type from “ALL,”
“BAND” and “PROGxx
(xx= 0–24).”
oPush [CALL] (
MODE
•
SCAN
) to start the VFO scan watch.
• The transceiver checks the memory channel(s) every 5 sec.
• The watch resumes according to the selected scan resume con-
dition. (p. 41)
!0While pushing and holding [FUNC], push [SQL] (
ATT
•
SET
)
to cancel the watch and scan.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOPSKIP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOPSKIP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOPSKIP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOPSKIP
MR
5
1
9
• During VFO scan watch
Searches VFO frequen-
cies for 5 sec.
Pauses on a memory (bank)
channel when a signal is received.
• During VFO scan watch with priority beep
Emits beep and blinks “S” indicator when a signal is re-
ceived on a memory (bank) channel.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
Priority ON Priority beep ON
8
Push Push and hold Dual operation
