■ Battery pack (BP-243)
• Capacity : 1800 mAh
• Battery voltage : 3.7 V
• Charging temp. range : 0°C to +40°C; +32°F to +104°F
• Usable temp. range : –20°C to +60°C; –4°F to +140°F
• Storage temp. range :
Within 1 month –20°C to +50°C; –4°F to +122°F
Within 3 months –20°C to +35°C; –4°F to +95°F
Within 1 year –20°C to +20°C; –4°F to +68°F
• Dimensions : 35.3(W)×11.4(H)×53.1(D) mm;
(projections not included) 1
3
⁄8(W)×
7
⁄16(H)×2
3
⁄32(D) in
• Charging period
(approx.) :3 hrs.
• Battery life*
1
(approx.) : 20 hrs.
*
1
Operating periods are calculated under the following conditions;
Tx : Rx : standby =5 : 5 : 90, power save function: auto setting is activated
■ Battery charger (BC-164)
• Power supply : 12 to 16 V DC or the specified Icom
AC adapter (BC-145LA/LE/LV)
• Charging current : 760 mA±10%
• End voltage : 4.2 V±0.1 V
• Charging temp. range : +5°C to +35°C; +41°F to +95 °F
• Dimensions : 67(W)×86.5(H)×50(D) mm;
(projections not included)
2
5
⁄
8(W)×3
13
⁄
32(H)×1
31
⁄
32(D) in
•Weight
(approx.) : 95 g; 3.4 oz
76
14
SPECIFICATIONS
14
AM (at 10 dB S/N)
0.495–4.995 MHz Less than 2.2 µV
5.000–29.995 MHz Less than 1.4 µV
118.000–136.995 MHz Less than 1.4 µV
WFM (at 12 dB SINAD)
76.000–107.995 MHz Less than 1.8 µV
600–799.990 MHz Less than 2.5 µV
• Selectivity :
FM, AM More than 12 kHz/6 dB
Less than 30 kHz/60 dB
WFM More than 150 kHz/10 dB
Less than 700 kHz/20 dB
• Spurious and image rejection ratio:
More than 40dB
• Audio output power : More than 50 mW at 10%
(at 3.7 V DC) distortion with an 8 Ω load
D Transmitter
• Modulation system : Variable reactance frequency
modulation
• Output power (at 3.7 V DC) :
144 MHz High 1.5 W, Low 0.1 W
(approx.)
440 MHz High 1.0 W, Low 0.1 W (approx.)
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dB (High power)
Less than –50 dB (Low power)
