25
6
MEMORY/CALL CHANNELS
The IC-P7A has a total of 18 banks (A to H, J, L, N, O to R, T, U
and Y). Regular memory channels, 000 to 999, may assigned
into a desired bank for easy memory management.
qPush and hold [V/M] (
SKIP
•
S
.
MW
) for 1 sec. to enter select
memory write mode.
•1 short and 1 long beep sound.
•“ ” indicator and memory channel number blink.
wRotate [DIAL] to select the desired memory channel.
eWhile pushing and holding [CALL] (
MODE
•
SCAN
), rotate
[DIAL] to select “BANK.”
•After releasing [CALL] (
MODE
•
SCAN
), “-- -- -- --” is displayed in-
stead of the frequency indication, and only “ ” indicator blinks.
• Bank group and channel number is displayed if the selected
memory channel has already been assigned to a bank.
•“BANK” can can also be selected by pushing [CALL]
(
MODE
•
SCAN
) several times.
rWhile pushing and holding [BAND] (
TS
•
LOCK
), rotate
[DIAL] to select the desired bank.
• Banks A to H, J, L, N, O to R, T, U and Y are available.
• The bank can also be selected by pushing [BAND] (
TS
•
LOCK
)
several times.
tRotate [DIAL] to select the desired bank channel number.
•Vacant bank channel numbers are only be displayed.
yPush and hold [V/M] (
SKIP
•
S
.
MW
) for 1 sec. to set the chan-
nel into the bank.
• Return to the previous indication.
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
Bank channel is selected with
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
Bank is selected with
+
SCAN
S.MW
SET
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
ATT
DTCS
TSQL
WFMAM
-
DUP
LOW
VOL PRIOP S K IP
MR
5
1
9
S.MW
[DIAL]
After [CALL]
released
SCAN
■ Memory bank setting
