Function Details SiE25-110
96 Function and Operation
4.2.27 Setting mode
Test Run Control When carrying out cooling operation first time after installation and by pushing TEST RUN
button on the indoor unit remote controller, the unit runs for about 3 minutes in "Test Run
Mode".
When carrying out operation first time in heating mode after installation, the unit will not run
in the "Test Run Mode".
Further, when carrying out heating operation by pushing the TEST RUN button on the indoor
unit remote controller, the unit will not run in the "Test Run Mode" too. (Carries out heating
operation in forced thermostat ON.)
In the "Test Run Mode", senses on-site installation status including failure to open stop
300valves, etc. and determines malfunction immediately. When "U0" malfunction code is
displayed, check the on-site installation status for failure to open stop valves, etc.
When the malfunction code is not displayed, continues cooling operation.
(This control is carried out again when turning power on first time after refrigerant collection
by pump down switch is complete.)
Outdoor Unit Low
Noise Control
A. Setting by dip switch
[Night-time automatic low noise setting]
When setting dip switches DS1-3 on the outdoor unit PC board to ON, carries out low noise
operation by presuming the current time in accordance with changes of outside temperature
and automatically restricting the number of revolutions of outdoor unit fan and operating
frequency of compressor at night (22 to 8 o’clock). (Time at night is a target only.)
B. Setting via contact input (manual low noise setting)
When short circuit between
T
1
and T
2
on terminal block X1M mounted on the outdoor unit PC
board, carries out low noise operation by restricting the outdoor unit fan speed and operating
frequency of compressor.
Condition
A
Condition
B
Condition
C
Indoor unit heat exchange temp.>34˚C
888
Indoor unit heat exchange temp.>Indoor unit intake temp.+17˚C
(+12˚C if outside temperature is below 5˚C)
88
—
Indoor unit heat exchange temp.>Indoor unit intake temp.+22˚C
(+20˚C if outside temperature is below 5˚C)
——
8
3 minutes elapsed after compressor startup
8
——
5.5 minutes elapsed after compressor startup —
8
—
10.5 minutes elapsed after compressor startup — —
8
Cooling
First operation after installation
Cooling operation in test run mode
(for about 3 minutes)
Normal cooling operation
{
&
Cooling
TEST RUN button ON
Cooling operation in test run mode
(for about 3 minutes)
Cooling operation in forced
thermostat ON
{
&
Heating
First operation after installation
Normal heating operation
{
&
Heating
TEST RUN button ON
Heating operation in forced
thermostat ON
{
&
(S2570)
