SiE25-110 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 189
Check No. 6 If the low pressure is abnormally low
Conception
Abnormally low pressure level is mostly caused by the evaporator side.
The following contents are provided based on field checking of service engineer.
Further, the number is listed in the order of degree of influence.
a. In cooling operation
Check items (Possible causes) Judgment
1. Does the outdoor unit fan run normally? 1. Visual inspection
2. Is the indoor unit filter clogged? 2. Visual inspection
3. Is there clogging before or after the EV
(capillary)?
3. Check if there is a temperature
difference before and after EV
(capillary).
Check if the main valve unit of EV
operates (by noise, vibration).
4. Is the check valve clogged? 4. Check if there is a temperature
difference before and after check valve.
→If YES, the check valve is caught.
5. Is the LPS normal? 5. Check continuity using a tester.
6. Is the indoor unit installed under such
conditions that short circuit easily
occurs?
6. Visual inspection
7. Is the refrigerant gas short? 7. Conduct refrigerant collection and
vacuum drying, and then add proper
amount refrigerant.
a. In heating operation
Check items (Possible causes) Judgment
1. Does the outdoor unit fan run normally? 1.Visual inspection
2. Is the outdoor unit heat exchanger
clogged?
2. Visual inspection
3. Is the outdoor unit installed under such
conditions that short circuit easily
occurs?
3. Visual inspection
4. Is there clogging before or after the EV
(capillary)?
4. Check if there is a temperature
difference before and after EV
(capillary).
Check if the main valve unit of EV
operates (by noise, vibration).
5. Is the check valve clogged? 5. Check if there is a temperature
difference before and after check valve.
→If YES, the check valve is caught.
6. Is the LPS normal? 6. Check continuity using a tester.
7. Is the refrigerant gas short? 7. Conduct refrigerant collection and
vacuum drying, and then add proper
amount refrigerant.
