SiE25-110 Function Details
Function and Operation 89
4.2.17 Discharge pipe temperature protection control
Controls motorized valve opening degree and compressor operation frequency
to prevent compressor internal temperature from abnormal rising.
[Operation frequency control]
Td: Discharge pipe temperature of compressor (˚C)
[Motorized valve opening degree control]
Model RZP71D Model RZP100~140D
A˚C 100˚C 100˚C
B˚C 105˚C 105˚C
C˚C 110˚C 110˚C
D˚C 120˚C 120˚C
E˚C 125˚C 135˚C
FHz 81Hz 62Hz
Gmin 15min 10min
Model RZP71D Model RZP100~140D
M˚C 95˚C 95˚C
N˚C 80˚C
(S2549)
OR
OR
300 sec
Td≥C˚C continues
for G minutes
OR
&
&
Normal operation
Compressor upper limit frequency
-1 step/30 sec
Compressor upper limit frequency
+1 step/1 min
Compressor upper limit frequency
F Hz
Compressor stop
Stopped 11 times
in 200 minutes
10 times or less stopping in 200 minutes
Upper limit frequency
= Maximum frequency
5 min elapsed
Malfunction stop (F3 indication)
Td>B˚C
Td>C˚C
Td<B˚C
Td<B˚C
Td<A˚C
Td>D˚C
Td≥E˚C
(S2550)
Normal operation
Compressor upper limit frequency
+5 pls/2 min when cooling,
1 min when heating
Td>M˚C Td>N˚C
