SiE25-110
Troubleshooting 99
Part 8
Troubleshooting
1. Maintenance Inspections ....................................................................101
1.1 Optimal Operation Condition ............................................................... 101
1.2 Cautions in Handling New Refrigerant ................................................ 104
2. How to Handle Request for Maintenance ...........................................106
2.1 Flow Chart ........................................................................................... 106
3. Troubleshooting Based on Equipment Condition................................107
3.1 Troubleshooting Based on Equipment Condition ................................ 107
3.2 Equipment does not Operate............................................................... 108
3.3 Indoor Fan Operates, but Compressor does not................................. 109
3.4 Cooling/Heating Operation Starts but Stops Immediately. .................. 111
3.5 After Equipment Shuts Down, It cannot be Restarted for a While....... 112
3.6 Equipment Operates but does not Provide Cooling. ........................... 113
3.7 Equipment Operates but does not Provide Heating. ........................... 115
3.8 Equipment Discharges White Mist....................................................... 116
3.9 Equipment Produces Loud Noise or Shakes....................................... 117
3.10 Equipment Discharges Dust................................................................ 118
3.11 Remote Controller LCD Displays "88"................................................. 119
3.12 Swing Flap does not Operate.............................................................. 120
4. Procedure of Self-Diagnosis by Remote Controller ............................121
4.1 The INSPECTION/TEST Button.......................................................... 121
4.2 Self-Diagnosis by Wired Remote Controller........................................ 122
4.3 Fault Diagnosis by Wireless Remote Controller.................................. 123
4.4 Remote Controller Display Malfunction Code and Contents ............... 125
5. Procedure of Self-Diagnosis by LED...................................................127
5.1 Troubleshooting by LED on the Indoor Unit’s...................................... 127
5.2 Troubleshooting by LED on Inverter Outdoor Unit PCB...................... 128
6. Troubleshooting by Remote Controller Display / LED Display............130
6.1 Explanation for Symbols...................................................................... 130
6.2 Malfunction Code and LED Display Table........................................... 131
6.3 Failure of Indoor Unit PC Board .......................................................... 134
6.4 Malfunction of Drain Water Level System (Float Type)....................... 135
6.5 Failure of Drain System....................................................................... 137
6.6 Indoor Unit Fan Motor Lock................................................................. 138
6.7 Malfunction of Indoor Unit Fan Motor .................................................. 139
6.8 Swing Flap Motor Malfunction / Lock................................................... 141
6.9 Failure of Capacity Setting .................................................................. 143
6.10 Malfunction of Heat Exchange Temperature Sensor System.............. 144
6.11 Malfunction of Suction Air Temperature Sensor System..................... 145
6.12 Malfunction of Remote Controller Air Thermistor ................................ 146
6.13 Malfunction of Moisture Sensor System.............................................. 147
6.14 Actuation of Protection Device ............................................................ 148
6.15 Failure of Outdoor Unit PC Board........................................................ 149
6.16 Abnormal High Pressure Level............................................................ 150
6.17 Low Pressure System (LPS) Malfunction............................................ 152
