SiE25-110 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 173
6.31 Open Phase
Remote
Controller
Display
P1
Outdoor Unit LED
Display
A 9 1 4 2 3 3 3 4 4
Applicable
Models
RZP71~140D
Method of
Malfunction
Detection
Malfunction is detected according to the voltage waveform of main circuit capacitor built in
inverter.
Malfunction
Decision
Conditions
When the aforementioned voltage waveform becomes identical with the waveform of the power
supply open phase.
Supposed
Causes
Open phase
Voltage imbalance between phases
Faulty main circuit capacitor
Power unit (Disconnection in diode module)
Faulty outdoor unit PC board
Faulty Magnetic Relay (K11R, K12R)
Improper main circuit wiring
