SiE25-110 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 179
6.36 Abnormal Power Supply Voltage
Remote
Controller
Display
U2
LED Display Refer to P.133
Applicable
Models
RZP71~140D
Method of
Malfunction
Detection
Malfunction is detected according to the voltage of main circuit capacitor built in the inverter and
power supply voltage.
Malfunction
Decision
Conditions
When the voltage of main circuit capacitor built in the inverter and power supply voltage drop
(150-170 VAC) or when the power failure of several tons of ms or longer is generated.
* Remote controller does not decide the abnormality.
Supposed
Causes
Drop in power supply voltage (180 V or less)
Instantaneous power failure
Inverter open phase (Phase T)
Faulty main circuit wiring
Faulty outdoor unit PC board
Main circuit parts damaged
