Daikin RZP100DVAL [92/255] Simulated operation function
![Daikin RZP125DV1 [92/255] Simulated operation function](/views2/1782863/page92/bg5c.png)
SiE25-110 Function Details
Function and Operation 83
4.2.4 Simulated operation Function
Outside temperature thermistor
Outdoor unit heat exchange thermistor
Fin thermistor
Discharge pipe thermistor
Indoor unit suction thermistor
Indoor unit heat exchanger thermistor
When malfunctions, quasi-operation is conducted while displaying the applicable alarm. (If the
fin thermistor malfunctions, the alarm is not displayed on the remote controller, and displayed
only when pushing Inspection Button.)
If low pressure sensor or suction pipe thermistor malfunctions, compressor stops operation due
to malfunction and does not conduct the simulated-operation.
4.2.5 Capacitor Discharging Control
Outputs non-phase waveform for condenser to discharge for about 1 minute after K11R turns
OFF (remote controller stop, stop due to malfunction, compressor and outdoor unit fan motor
stop with thermostat OFF in the retry system).
4.2.6 Thermostat ON/OFF judgement
Room temperature thermostat control
Thermostat ON ∆Trs ≥ 0˚C
Thermostat OFF Executes thermostat OFF when either one of the following conditions is met.
∆Trs ≤ –1.0˚C continues for 1 minutes.
Cooling: ∆Trs ≤ –2.5˚C
Heating: ∆Trs ≤ –3.0˚C
∆Trs ≥ 1.0˚C changed suddenly into ∆Trs ≥–1.5˚C.
∆Trs = [Indoor suction temperature] - [Remote controller set temperature] –0.5˚C
4.2.7 “Automatic Operation Mode” Control (PMV Control)
When selecting “Automatic Operation Mode” with the remote controller, conducts the most
comfortable operation in which you do not feel too cool or too hot.
Outdoor air temperature
Indoor air temperature
Remote controller set temperature
Calculates and controls the
optimum indoor temperature
(S2565)
