Function Details SiE25-110
86 Function and Operation
4.2.11 Fan step table
RZP71D
RZP100D
RZP125D
4 way valve OFF ON
Operation mode Cooling cycle Heating cycle
Outdoor unit
fan step
0 step 0 rpm
1 250
2 300
3 360
4 430
5 515
6 619 542
7 750
8 870 839
4 way valve OFF ON
Operation mode Cooling cycle Heating cycle
Fan M1F M2F M1F M2F
Outdoor unit
fan step
0 step 0 rpm 0 rpm 0 rpm 0 rpm
1 250 0 250 0
2 365 0 285 250
3 285 250 345 310
4 370 335 425 390
5 480 445 520 485
6 620 585 620 585
7 740 705 740 705
8 850 815 801 766
4 way valve OFF ON
Operation mode Cooling cycle Heating cycle
Fan M1F M2F M1F M2F
Outdoor unit
fan step
0 step 0 rpm 0 rpm 0 rpm 0 rpm
1 250 0 250 0
2 365 0 285 250
3 285 250 345 310
4 370 335 425 390
5 480 445 520 485
6 620 585 620 585
7 740 705 740 705
8 885 850 857 822
