Troubleshooting by Remote Controller Display / LED Display SiE25-110
168 Troubleshooting
Troubleshooting
Compressor inspection
Inspect according to the diagnosis
procedure for abnormal noises,
vibration, operating status, etc.
of the compressor.
Compressor overload
Inspection of the compressor
and refrigerant system is required.
YES
NO
Turn the main power supply
off, and then disconnect the
connection between the
compressor and inverter.
Is the
secondary current of
the inverter higher than
0
A (see below) for
each phase?
NO
Replace the inverter PC board.
YES
NO
Replace the inverter PC board.
YES
Is
the
inverter output
voltage generated
approximately at the same
increasing speed on each
phase after turning on
again? (*)
(U-V, V-W,
W-U)
*
When operating compressor with compressor output line
disconnected, the compressor stops due to malfunction after
elapsed time of 5 seconds. Therefore, check the voltage increase
for 5 seconds.
Detection value
0
Electronic thermal detection value
Continuity check in
the power
transistor (IGBT)
Is the continuity
normal?
Check No. 10
RZP71D
RZP100 ~ 140D
Cooling
Heating
Cooling
Heating
22A × 5 seconds or
13.6A (cooling), 15.1A
(heating) × 260 seconds
33A × 5 seconds or
26A × 260 seconds
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
(S2593)
