SiE25-110 Specifications
Specifications 19
FHYCP (Ceiling Mounted Cassette Type)
Notes: 1. Nominal capacities are based on the following conditions:
2. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
3. In case of drain piping for outdoor unit, drain piping kit (option) is needed.
Model
Indoor Units FHYCP125DVL FHYCP140DVL
Outdoor Units RZP125DTAL RZP140DTAL
1 Cooling Capacity (1)/(2)
kW
12.5 / 12.7
(6.0~14.3) / (6.1~14.5)
14.0 / 14.2
(6.2~15.8) / (6.3~16.1)
Btu/h
42,600 / 43,300
(20,400~48,800) / (20,800~49,500)
47,700 / 48,400
(21,100~53,900) / (21,500~54,900)
kcal/h
10,700 / 10,900
(5,100~12,200) / (5,200~12,400)
12,000 / 12,200
(5,300~13,500) / (5,400~13,800)
1 Heating Capacity (1)/(2)
kW
14.0 / 14.0
(6.0~16.2) / (6.0~16.2)
16.0 / 16.0
(6.2~18.1) / (6.2~18.1)
Btu/h
47,700 / 47,700
(20,400~55,300) / (20,400~55,300)
54,600 / 54,600
(21,100~61,700) / (21,100~61,700)
kcal/h
12,000 / 12,000
(5,100~13,900) / (5,100~13,900)
13,700 / 13,700
(5,300~15,500) / (5,300~15,500)
Indoor Units FHYCP125DVL FHYCP140DVL
Dimensions H×W×Dmm 288×840×840 288×840×840
Coil
Type Cross Fin Coil (Waffle Louver Fins and N-hix Tubes)
Row×Stages×Fin Pitch 2×12×1.2 2×12×1.2
Face Area m² 0.544 0.544
Fan
Model QTS46C17M QTS46C17M
Type Turbo Fan Turbo Fan
Motor Output W 120 120
Air Flow Rate m³/min. (H) 30 (L) 24 (H) 33 (L) 25
Air Filter — —
Machine Weight kg 28 28
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ19.1 (Flare) φ19.1 (Flare)
Drain mm I. D
φ25×O. Dφ32 I. Dφ25×O. Dφ32
Remote Controller
(Option)
Wired BRC1C61 BRC1C61
Wireless BRC7E61W BRC7E61W
Decoration
Panel (Option)
Model BYCP125D-W1 BYCP125D-W1
Color White White
Dimensions (H×W×D) mm 45×950×950 45×950×950
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Weight kg 5.5 5.5
Outdoor Units RZP125DTAL RZP140DTAL
Color Pale Ivory Pale Ivory
Dimensions H×W×Dmm 1,435×900×320 1,435×900×320
Coil
Type Cross Fin Coil (Waffle Fins and NHi-XA Tubes)
Row×Stages×Fin Pitch 2×64×1.4 2×64×1.4
Face Area m² 1.598 1.598
Comp.
Model JT100FAVD JT100FAVD
Type Hermetically Sealed Scroll Type
Motor Output kW 2.4 2.9
Fan
Model P47M11F×2P47M11F×2
Type Propeller Propeller
Motor Output W 55+55 55+55
Air Flow Rate m³/min. 102 102
Machine Weight kg 119 119
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ19.1 (Flare) φ19.1 (Flare)
Drain mm
φ26.0 (Hole) φ26.0 (Hole)
Safety Devices High Pressure Switch. Fuse.
Capacity Control Compressor Revolution Speed Control (Inverter System)
Refrigerant Control Expansion Valve (Electronic Type)
Ref.Piping
Max. Length m 70 (Equivalent Length 90m) 70 (Equivalent Length 90m)
Max. Height Difference m 30 30
Refrigerant
Model R-407C R-407C
Charge kg 5.0 (Charged for 30m) 5.0 (Charged for 30m)
Ref. Oil
Model DAPHNE FVC68D DAPHNE FVC68D
Charge L 1.2 1.2
Drawing No. 4D034047
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Mark Cooling Heating Piping length
(1)
Indoor: 27˚CDB, 19.0˚CWB
Outdoor: 35˚CDB, 24˚CWB
Indoor: 20˚CDB, 15˚CWB
Outdoor: 7˚CDB, 6˚CWB
7.5m
(Horizontal)
(2)
Indoor: 27˚CDB, 19.5˚CWB
Outdoor: 35˚CDB, 24˚CWB
Indoor: 21˚CDB, 15˚CWB
Outdoor: 7˚CDB, 6˚CWB
5m
(Horizontal)
