SiE25-110 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 163
6.25 Malfunction of Suction Pipe Pressure Sensor
Remote
Controller
Display
JC
Outdoor Unit LED
Display
A 5 1 4 2 4 3 3 4 3
Applicable
Models
RZP71 ~ 140D
Method of
Malfunction
Detection
Malfunction
Decision
Conditions
Supposed
Causes
Faulty low pressure sensor
Connection of low pressure sensor with wrong connection
Faulty outdoor unit PC board
Incorrect connection of connector
Troubleshooting
Is low
pressure sensor
connector connected
to outdoor unit
PC board?
NO
NO
YES
YES
Is
the relationship
between low pressure
and VL normal?
Connect the low pressure
sensor, and turn on again.
Replace the outdoor unit
PC board (A1P).
Replace the low pressure
sensor.
Measure voltage (VL)
between pins 2 and 3
of the above connector.
0
See Check No. 13 for “Voltage measuring procedure (sensor pressure and voltage characteristics).
Check No. 13
(S2591)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
