Specifications SiE25-110
14 Specifications
FHYP (Ceiling Suspended Type: Pair System)
Notes: 1. Nominal capacities are based on the following conditions:
2. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
3. In case of drain piping for outdoor unit, drain piping kit (option) is needed.
Model
Indoor Units FHYP71BV1 FHYP100BV1 FHYP125BV1
Outdoor Units RZP71DV1 RZP100DV1 RZP125DV1
1 Cooling Capacity
kW 7.1 (3.3~8.0) 10.0 (5.0~11.4) 12.5 (6.0~14.3)
Btu/h 24,200 (11,200~27,300) 34,100 (17,000~38,900) 42,600 (20,400~48,800)
kcal/h 6,100 (2,800~6,800) 8,600 (4,300~9,800) 10,700 (5,100~12,200)
1 Heating Capacity
kW 8.0 (3.5~9.0) 11.2 (5.6~12.8) 14.0 (6.0~16.2)
Btu/h 27,300 (11,900~30,700) 38,200 (19,100~43,600) 47,700 (20,400~55,300)
kcal/h 6,800 (3,000~7,700) 9,600 (4,800~11,000) 12,000 (5,100~13,900)
Indoor Units FHYP71BV1 FHYP100BV1 FHYP125DV1
Color White White White
Dimensions H×W×Dmm195×1,160×680 195×1,400×680 195×1,590×680
Coil
Type Cross Fin Coil (Multi Louver Fins and N-hix Tubes)
Row×Stages×Fin Pitch 3×12×1.75 3×12×1.75 3×12×1.75
Face Area m² 0.233 0.293 0.341
Fan
Model 4D12K1AA1 3D12K2AA1 4D12K2AA1
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output W 62 130 130
Air Flow Rate m³/min. (H) 17 (L) 14 (H) 24 (L) 20 (H) 30 (L) 25
Air Filter — — —
Weight kg 27 32 35
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ15.9 (Flare) φ19.1 (Flare) φ19.1 (Flare)
Drain mm I. D
φ20×O. Dφ26 I. Dφ20×O. Dφ26 I. Dφ20×O. Dφ26
Remote Controller
(Option)
Wired BRC1C61 BRC1C61 BRC1C61
Wireless BRC7E63W BRC7E63W BRC7E63W
Outdoor Units RZP71DV1 RZP100DV1 RZP125DV1
Color Pale Ivory Pale Ivory Pale Ivory
Dimensions H×W×Dmm905×900×320 1,435×900×320 1,435×900×320
Coil
Type Cross Fin Coil (Waffle Fins and NHi-XA Tubes)
Row×Stages×Fin Pitch 2×40×1.4 2×64×1.4 2×64×1.4
Face Area m² 0.991 1.598 1.598
Comp.
Model 2YC63AXD JT100FAVD JT100FAVD
Type Hermetically Sealed Swing Type Hermetically Sealed Scroll type
Motor Output kW 1.9 1.9 2.4
Fan
Model P47M11F P47M11F×2P47M11F×2
Type Propeller Propeller Propeller
Motor Output W 55 55+55 55+55
Air Flow Rate m³/min. 53 97 102
Weight kg 71 119 119
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ15.9 (Flare) φ19.1 (Flare) φ19.1 (Flare)
Drain mm
φ26.0 (Hole) φ26.0 (Hole) φ26.0 (Hole)
Safety Devices High Pressure Switch. Fuse.
Capacity Control Compressor Revolution Speed Control (Inverter System)
Refrigerant Control Expansion Valve (Electronic Type)
Ref.Piping
Max. Length m 50 (Equivalent Length 70m) 70 (Equivalent Length 90m) 70 (Equivalent Length 90m)
Max. Height Difference m 30 30 30
Refrigerant
Model R-407C R-407C R-407C
Charge kg 3.2 (Charged for 30m) 5.0 (Charged for 30m) 5.0 (Charged for 30m)
Ref. Oil
Model DAPHNE FVC50K DAPHNE FVC68D DAPHNE FVC68D
Charge L 0.65 1.20 1.20
Drawing No. C : 4D034212
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Mark Cooling Heating Piping length Hz-Volts
(1) Indoor: 27˚CDB, 19.0˚CWB
Outdoor: 35˚CDB, 24˚CWB
Indoor: 20˚CDB, 15˚CWB
Outdoor: 7˚CDB, 6˚CWB
7.5m
(Horizontal)
50Hz-230V
(2) Indoor: 27˚CDB, 19.5˚CWB
Outdoor: 35˚CDB, 24˚CWB
