Specifications SiE25-110
18 Specifications
1.2 60Hz
FHYCP (Ceiling Mounted Cassette Type)
Notes: 1. Nominal capacities are based on the following conditions:
2. Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
3. In case of drain piping for outdoor unit, drain piping kit (option) is needed.
Model
Indoor Units FHYCP71DVL FHYCP100DVL
Outdoor Units RZP71DVAL RZP100DVAL
1 Cooling Capacity (1)/(2)
kW
7.1 / 7.2
(3.3~8.1) / (3.4~8.2)
10.0 / 10.1
(5.0~11.4) / (5.1~11.6)
Btu/h
24,200 / 24,500
(11,200~27,600) / (11,600~27,900)
34,100 / 34,400
(17,000~38,900) / (17,400~39,600)
kcal/h
6,100 / 6,100
(2,800~6,900) / (2,900~7,000)
8,600 / 8,600
(4,300~9,800) / (4,300~9,900)
1 Heating Capacity (1)/(2)
kW
8.0 / 8.0
(3.5~9.0) / (3.5~9.0)
11.2 / 11.2
(5.6~12.8) / (5.6~12.8)
Btu/h
27,300 / 27,300
(11,900~30,700) / (11,900~30,700)
38,200 / 38,200
(19,100~43,600) / (19,100~43,600)
kcal/h
6,800 / 6,800
(3,000~7,700) / (3,000~7,700)
9,600 / 9,600
(4,800~11,000) / (4,800~11,000)
Indoor Units FHYCP71DVL FHYCP100DVL
Dimensions H×W×Dmm 246×840×840 288×840×840
Coil
Type Cross Fin Coil (Waffle Louver Fins and N-hix Tubes)
Row×Stages×Fin Pitch 2×10×1.2 2×12×1.2
Face Area m² 0.454 0.544
Fan
Model QTS46D14M QTS46C17M
Type Turbo Fan Turbo Fan
Motor Output W 30 120
Air Flow Rate m³/min. (H) 19 (L) 14 (H) 26 (L) 21
Air Filter — —
Machine Weight kg 24 28
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ15.9 (Flare) φ19.1 (Flare)
Drain mm I. D
φ25×O. Dφ32 I. Dφ25×O. Dφ32
Remote Controller
(Option)
Wired BRC1C61 BRC1C61
Wireless BRC7E61W BRC7E61W
Decoration
Panel (Option)
Model BYCP125D-W1 BYCP125D-W1
Color White White
Dimensions (H×W×D) mm 45×950×950 45×950×950
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Weight kg 5.5 5.5
Outdoor Units RZP71DVAL RZP100DVAL
Color Pale Ivory Pale Ivory
Dimensions H×W×Dmm 905×900×320 1,435×900×320
Coil
Type Cross Fin Coil (Waffle Fins and NHi-XA Tubes)
Row×Stages×Fin Pitch 2×40×1.4 2×64×1.4
Face Area m² 0.991 1.598
Comp.
Model 2YC63AXD JT100FA-VD
Type Hermetically Sealed Swing Type Hermetically Sealed Scroll Type
Motor Output kW 1.9 1.9
Fan
Model P47M11F P47M11F×2
Type Propeller Propeller
Motor Output W 55 55+55
Air Flow Rate m³/min. 53 97
Machine Weight kg 71 119
Piping
Connections
Liquid mm
φ9.5 (Flare) φ9.5 (Flare)
Gas mm
φ15.9 (Flare) φ19.1 (Flare)
Drain mm
φ26.0 (Hole) φ26.0 (Hole)
Safety Devices High Pressure Switch. Fuse.
Capacity Control Compressor Revolution Speed Control (Inverter System)
Refrigerant Control Expansion Valve (Electronic Type)
Ref.Piping
Max. Length m 50 (Equivalent Length 70m) 70 (Equivalent Length 90m)
Max. Height Difference m 30 30
Refrigerant
Model R-407C R-407C
Charge kg 3.2 (Charged for 30m) 5.0 (Charged for 30m)
Ref. Oil
Model DAPHNE FVC50K DAPHNE FVC68D
Charge L 0.65 1.2
Drawing No. 4D034046
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Mark Cooling Heating Piping length
(1)
Indoor: 27˚CDB, 19.0˚CWB
Outdoor: 35˚CDB, 24˚CWB
Indoor: 20˚CDB, 15˚CWB
Outdoor: 7˚CDB, 6˚CWB
7.5m
(Horizontal)
(2)
Indoor: 27˚CDB, 19.5˚CWB
Outdoor: 35˚CDB, 24˚CWB
Indoor: 21˚CDB, 15˚CWB
Outdoor: 7˚CDB, 6˚CWB
5m
(Horizontal)
