FHYCP71~140D SiE25-110
206 Removal Procedure
3. Disconnect the power
supply PC board.
1
Disengage the 3 tabs
on the front by pressing
the back of the PC
board in the direction
shown by the arrow,
then remove the power
supply PC board.
Step
Procedure Points
