Hitachi CS51EA [9/112] English
![Hitachi CS51EA [9/112] English](/views2/1081739/page9/bg9.png)
9
English
Transport and storage
○ Carry the unit/machine by hand with the engine stopped and the
muffl er away from your body.
○ Allow the engine to cool, empty the fuel tank, and secure the
unit/machine before storing or transporting in a vehicle.
○ Empty the fuel tank before storing the unit/machine. It is
recommended that the fuel be emptied after each use. If fuel is
left in the tank, store so fuel will not leak.
○ Store unit/machine out of the reach of children.
○ Clean and maintain the unit carefully and store it in a dry place.
○ Make sure stop switch is off when transporting or storing.
○ When transporting or storage, cover chain with guide bar cover.
If situations occur which are not covered in this manual, take care
and use common sense. Contact Hitachi Authorized Service
Centers if you need assistance. Pay special attention to statements
preceded by the following words:
WARNING
Indicates a strong possibility of severe personal injury or loss of
life, if instructions are not followed.
CAUTION
Indicates a possibility of personal injury or equipment damage, if
instructions are not followed.
NOTE
Helpful information for correct function and use.
WARNING
KICKBACK DANGER (Fig. 1)
One of the most severe dangers when working with a chain saw is
the possibility of kickback. Kickback may occur when the upper tip
of the guide bar touches an object, or when the wood closes in and
pinches the saw chain in the cut. Tip contact in some cases may
cause a lightning fast reverse reaction, kicking the guide bar up and
back toward you. Pinching the saw chain along the top of the guide
bar may also push the guide bar rapidly back towards you. Either of
these reactions may cause you to lose control of the saw which could
result in serious personal injury. Even though your saw has safety
built into its design, you should not rely on these safety features
exclusively. Know where your bar tip is at all times. Kickback does
occur if you allow the kickback zone (1) of the bar to touch an object.
Do not use that area. Kickback from pinching is caused by a cut
closing and pinching the upper side of the guide bar. Study your cut
and make sure it will open as you cut through. Maintain control when
the engine is running by always keeping a fi rm grip on the saw with
your right hand on the rear handle, your left hand on the front handle
and your thumbs and fi ngers encircling the handles. Always hold the
saw with both hands during operation and cut at high engine speed.
Follow manufacturer's sharpening and maintenance instructions
for the saw chain. The lack of this maintenance may increase the
possibility of kickback.
SPECIFICATIONS
○ Code “CS” of model name means “Chain saw”
Model
CS51EAP
(40S)
CS51EAP
(45S)
CS51EAP
(50S)
CS51EA
(40S)
CS51EA
(45S)
CS51EA
(50S)
Type of equipment Chain saw, portable
Engine Size (cm
3
) 50.1
Spark Plug NGK BPMR-7A
Fuel Tank Capacity (cm
3
)530
Chain Oil Tank Capacity (cm
3
)270
Dry Weight (kg)
(Without guide bar and chain)
5.2 5.1
Chain pitch (mm) 8.26
Chain gauge (mm) 1.27
Sound pressure level LpA (dB (A)) by ISO 22868
Equivalent
Uncertainty
100.2
1
100.9
1
Sound power level LwA (dB (A)) by ISO 22868
Measured
Uncertainty
Sound power level LwA (dB (A)) by 2000/14/EC
Measured
Guaranteed
113
2
114
117
113
2
114
117
Vibration level (m/s
2
) by ISO 22867
Front handle
Rear handle
Uncertainty
2.0
2.1
0.8
2.0
2.1
0.8
2.0
2.1
0.8
2.0
2.1
0.8
2.0
2.1
0.8
2.0
2.1
0.8
Guide bar length (mm) 400 450 500 400 450 500
Type of chain
95VPX
(Oregon)
20BPX
(Oregon)
95VPX
(Oregon)
20BPX
(Oregon)
Max. engine power
by ISO 7293 (kW)
2.4 2.5
Max. engine speed (min
-1
)13500
Idle engine speed (min
-1
) 3000
Specifi c fuel consumption at maximum engine
power (g/kWh)
430 439
Max. chain speed (m/sec) 26.0
Sprocket (number of teeth) 7
NOTE: Equivalent noise level/vibration levels are calculated as the time-weighted energy total for noise/vibration levels under various
working conditions with the following time distribution: 1/3 idle, 1/3 full, 1/3 racing speed.
*All data subject to change without notice.
