4
Useful transmission and reception functions
4-4 FK-506
Specifying F-codes when sending faxes
F-codes can be specified when the keypad is used to type in the fax number
of a recipient.
1 Using the keypad, type in the fax number of the recipient.
2 Press the [,] key.
The "FAX OTHER SETTING" menu appears.
3 Press the [+] or [,] key until "SUB, SID SETTING" is selected, and then
press the [OK] key.
Memory:100%
01234_
QUALITY:STD/TEXT
OTHER SETTING=
FAX OTHER SETTING
SUB,SID SETTING
TIMER SETTING
RETURN
