Konica Minolta bizhub 163R [72/318] Loading the document into the document feeder

Faxing

3-6 FK-506

3.2 Positioning the document

Loading the document into the document feeder

Reminder

Document pages bound with staples or paper clips can damage the

machine. Be sure to remove all staples and paper clips before faxing a

document.

1 Press the [Fax] key.

The machine enters Fax mode, and

the Fax mode screen appears.

2 Load the document into the document feeder with the side to be

scanned facing up.

– A maximum of 50 sheets of plain A3-size paper can be loaded.

– Only a single page can be loaded if the document has a length of

432 mm (17 inches) or more.
