6
Utility mode/Fax mode parameters
6-26 FK-506
4 Press the [+] or [,] key until "EDIT" or "DELETE" is selected, and then
press the [OK] key.
– If "EDIT" was selected, continue with the next step.
– If "DELETE" was selected, the settings registered with the one-
touch dial key are deleted and the "DIAL REGISTRATION" menu
appears again.
5 Change the name of the recipient, fax number, F-code settings (SUB
address and password) and communication speed.
– For details on changing the settings, refer to steps 4 through 6 of
"Registering one-touch dial destinations" on page 6-21.
When all settings have been specified, the "DIAL REGISTRATION"
menu appears again.
ONE-TOUCH DIAL 01
DELETE
EDIT
RETURN
ONE-TOUCH DIAL 01
:AAA TOKYO
NAME
