bizhub 163R
Инструкция по эксплуатации Страница: 235

Konica Minolta bizhub 163R [235/318] 0123456 destination

Konica Minolta bizhub 163fR [235/318] 0123456 destination

Utility mode/Fax mode parameters

FK-506 6-51

– When the switching plate is open in the upper position, the keys are

numbered 17 through 32.

4 Press the [+] or [,] key until "EDIT" or "DELETE" is selected, and then

press the [OK] key.

– If "EDIT" was selected, continue with the next step.

– If "DELETE" was selected, the registered program settings are

deleted and the "DIAL REGISTRATION" menu appears again.

5 If necessary, use the one-touch dial keys, speed dial numbers or

keypad to specify the recipients, and then press the [OK] key.

PROGRAM DIAL 32

DELETE

EDIT

RETURN

RELAY INITIATE

:0123456

DESTINATION
