Konica Minolta bizhub 163R [46/318] Entering text
![Konica Minolta bizhub 163R [46/318] Entering text](/views2/1121828/page46/bg2e.png)
2
Precaution
2-12 FK-506
2.4 Entering text
Follow the procedure described below to enter text when specifying the user
name or programming one-touch dial keys with the recipient name.
Changing the input mode
Each press of the [123/ABC] key switches between number input mode and
letter/symbol input mode.
[1...]: Numbers can be entered.
[A...]: Letters and symbols can be entered.
Key operation
Using the keypad, type in numbers, letters and symbols.
Switch between numbers and letters/symbols by pressing the [123/ABC]
key.
When "[1...]" appears in the display, numbers will be entered.
When "[A...]" appears in the display, letters/symbols will be entered.
The following characters can be entered with each key in the keypad.
Characters that can be entered with keypad
Keypad Available characters
[1...] [A...]
1 1 . (period) @ _ (underscore) - (hyphen) 1
22A B C 2 a b c
33D E F 3 d e f
4 4 G H I 4 g h i
5 5 J K L 5 j k l
66M N O 6 m n o
77P Q R S 7 p q r s
8 8 T U V 8 t u v
9 9 W X Y Z 9 w x y z
0 0 (space) 0
* + & / * = ! ? ( ) % [ ] ^ ’ ‘ { } | ~ $ , : ; < > "
###
