Internet faxing
5-16 FK-506
Selecting the setting for "MAX TX SIZE"
1 With the "BASIC/ADVANCED" menu displayed, select "ADVANCED",
and then press the [OK] key.
– For details on displaying the "BASIC/ADVANCED" menu, refer to
steps 1 through 3 in "Selecting BASIC/ADVANCED settings" on
page 5-14.
The "ADVANCED" menu appears.
2 Press the [+] or [,] key until "MAX TX SIZE" is selected, and then press
the [OK] key.
BASIC/ADVANCED
ADVANCED
BASIC
ADVANCED
MAX QUALITY
MAX TX SIZE
CODING METHOD
