Konica Minolta bizhub 163R [73/318] Fk 506 3 7

Faxing

FK-506 3-7

3 Slide the document guides to fit the size of document being loaded.

– Non-standard-sized documents with the following maximum sizes

can be scanned.

1000 mm

(39-1/4 inch)

297 mm

(11-3/4 inch)

210 mm

(Sizes less than 210 mm

are scanned as 210 mm.)

Paper feed

direction

Paper feed

direction

139.7 mm

(5-

1/2 inch)

Maximum size Minimum size
