2
Precaution
2-4 FK-506
No. Part name Description
1 Copy output tray Collects copies and printouts fed out facing down.
2 Front door Opened when replacing the toner bottle.
3 1st paper drawer • Can be loaded with up to 250 sheets of paper.
• The paper size can be adjusted freely.
• Special paper can be loaded.
4 Manual bypass tray • Used for manually feeding paper for making copies.
• Load only one sheet of paper at a time.
• Special paper can be loaded.
5 Right-side door release lever Used to open/close the right-side door.
6 Right-side door Opened when clearing paper misfeeds.
7 Mechanical counter Indicates the total number of copy and printout pages
that were printed.
8 RJ45 connector for networking
(optional)
Used for connecting the network cable when this ma-
chine is used for network printing.
9 USB connector Used for connecting a USB cable from the computer.
10 Telephone line connector (LINE) Used for connecting the telephone cord from the wall
jack.
11 Telephone jack (TEL) Used for connecting the cord from a telephone.
12 Power switch Used to turn the machine on and off.
13 Control panel Used to start copying or sending or to specify various
settings. (See p. 2-5.)
