Konica Minolta bizhub 163R [272/318] Selecting the paper drawer select tray parameter

Utility mode/Fax mode parameters

6-88 FK-506

Selecting the paper drawer ("SELECT TRAY" parameter)

1 Display the "FAX RX OPERATION" menu.

– Refer to "Displaying the "FAX RX OPERATION" menu" on

page 6-75.

2 Press the [+] or [,] key until "SELECT TRAY" is selected, and then

press the [OK] key.

3 Press the [+] or [,] key until the desired paper drawer is selected, and

then press the [OK] key.

UTILITY MODE

FAX RX OPERATION

FAX TX OPERATION

REPORTING

FAX RX OPERATION

SELECT TRAY

FOOTER

CLOSED NETWORK

SELECT TRAY

TRAY2

TRAY1

TRAY3
