Precaution

2-10 FK-506

Fax mode icons

Symbol Description

Dialing A fax number is being dialed.

Ringing The machine is being called.

Sending The document is being sent.

Receiving A document is being received.

In standby for timer

transmission

A document is queued for timer transmission.

In standby for poll-

ing transmission

A document is queued for polling transmission.

In standby for mail-

box reception

A mailbox reception document is ready to be printed.

Memory reception A document is being received and stored in the mem-

ory or has been received and stored in the memory.
