Utility mode/Fax mode parameters
6
FK-506 6-45
– When the switching plate is open in the upper position, the keys are
numbered 17 through 32.
4 Press the [+] or [,] key until "EDIT" or "DELETE" is selected, and then
press the [OK] key.
– If "EDIT" was selected, continue with the next step.
– If "DELETE" was selected, the registered program settings are
deleted and the "DIAL REGISTRATION" menu appears again.
5 Use the keypad to type in the transmission time, and then press the
[OK] key.
6 If necessary, change the recipient settings, and then press the [OK]
key.
The settings are registered, and the "DIAL REGISTRATION" menu
appears again.
PROGRAM DIAL 32
DELETE
EDIT
RETURN
TIMER TX
TIMER 18:00
