Konica Minolta bizhub 163R [191/318] Displaying the machine setting menu

Utility mode/Fax mode parameters

FK-506 6-7

Displaying the "MACHINE SETTING" menu

1 Press the [Utility] key.

The "UTILITY MODE" menu appears.

2 Press the [+] or [,] key until "MACHINE SETTING" is selected, and

then press the [OK] key.

3 Press the [+] or [,] key until the desired MACHINE SETTING parameter

is selected.

– The following MACHINE SETTING parameters are available.

AUTO PANEL RESET

ENERGY SAVE MODE

AUTO SHUT OFF

DENSITY (ADF)

DENSITY (BOOK)

PRINT DENSITY

LCD CONTRAST

KEY SPEED SETTING

LANGUAGE

BUZZER VOLUME

INITIAL MODE

SCAN THRESHOLD

UTILITY MODE

PAPER SOURCE SETUP

MACHINE SETTING

CUSTOM SIZE MEMORY
