Utility mode/Fax mode parameters
6
FK-506 6-29
– If settings are not to be specified for F-code transmission or the
communication speed, press the [OK] key. The settings are
registered, continue with step 8.
– To specify settings for F-code transmission or the communication
speed, press the [,], and then continue with the next step.
– For details on F-codes (SUB address and password), refer to
"Using F-codes" on page 4-3.
– If an e-mail address is entered for the destination and the [,] key is
pressed, the BASIC/ADVANCED settings can be specified. For
details on the BASIC/ADVANCED settings, refer to "Selecting
BASIC/ADVANCED settings" on page 5-14.
6 Press the [+] or [,] key until the parameter to be set is selected, and
then press the [OK] key.
– If "SUB, SID SETTING" was selected: Type in the SUB address and
password, and then press the [OK] key. A maximum of 20 digits can
be entered for the SUB address and password.
SPEED DIAL 011
MODEM SPEED
SUB,SID SETTING
RETURN
SUB
SID
:5555
:000_
