Useful transmission and reception functions
4-24 FK-506
5 Specify the relay station, and then press the [OK] key.
– For details on specifying the relay destination, refer to "Specifying
a recipient" on page 3-12.
6 Use the keypad to type in the relay box ID, and then press the [OK] key.
– Enter the relay box ID (20 digits or less) programmed at the relay
station.
– The only characters that can be used for the relay box ID are 0
through 9, * and #.
– To correct the entered number, press the [Clear/Stop] key, and then
type in the correct number.
RELAY INITIATE
DESTINATION
:0123456_
RELAY BOX ID
:1111_
