Faxing
3
FK-506 3-5
7 To begin scanning, press the [OK] key.
– To change the size of paper to be scanned, press the [,] key, and
then specify the size.
8 To continue scanning document pages, position the next document
page, and then press the [OK] key.
Repeat this step until all document pages have been scanned.
9 After all document pages have been scanned, press the [Start] key.
The transmission begins.
When the transmission is finished, a beep is sounded.
To stop the transmission, press the [Clear/Stop] key, and then select
"YES" in the screen that appeared.
!
Detail
For details on canceling the transmission of a scanned document, refer
to "Canceling (deleting) a queued transmission" on page 3-35.
If the fax could not be sent, a transmission report is printed. For details,
refer to "Checking communication results (reports/lists)" on page 3-39.
SCAN BOOK(AUTO)
SCAN=OK (SIZE= )
Memory:100%
QUALITY:STD/TEXT
NEXT PAGE?(AUTO)
SCAN=OK (TX=START)
Memory:100%
QUALITY:STD/TEXT
