Utility mode/Fax mode parameters
6-84 FK-506
Selecting the reception mode ("RX MODE" parameter)
1 Display the "FAX RX OPERATION" menu.
– Refer to "Displaying the "FAX RX OPERATION" menu" on
page 6-75.
2 Press the [+] or [,] key until "RX MODE" is selected, and then press
the [OK] key.
3 Press the [+] or [,] key until "AUTO RX" or "MANUAL RX" is selected,
and then press the [OK] key.
The "FAX RX OPERATION" menu appears again.
UTILITY MODE
FAX RX OPERATION
FAX TX OPERATION
REPORTING
FAX RX OPERATION
RX MODE
RX PRINT
FORWARD
RX MODE
MANUAL RX
AUTO RX
