Konica Minolta bizhub 163R [98/318] If the fax cannot be sent

Faxing

3-32 FK-506

3.6 If the fax cannot be sent

While faxing, if the recipient’s fax machine is busy or does not answer or if,

for any other reason, such as due to a transmission error, the fax is not sent

correctly, this machine automatically redials the fax number. The document

to be sent is treated as a queued fax waiting for redialing until the fax number

is redialed.

If the redialing or fax transmission could not be completed correctly, a

transmission result report is printed.

Note

For details on the transmission result report, refer to "Types of

reports/lists" on page 3-42.
