Konica Minolta bizhub 163R [19/318] Special text markings

Introduction

FK-506 1-9

Tips

Note

Text highlighted in this manner contains useful information and tips to

ensure safe use of the machine.

Reminder

Text highlighted in this manner contains information that should be

reminded.

Detail

Text highlighted in this manner contains references for more detailed

information.

Special text markings

[Stop] key

The names of keys on the control panel are written as shown above.

MACHINE SETTING

Display texts are written as shown above.
