1
Introduction
1-22 FK-506
other number for which charges exceed local or long-distance transmission
charges.)
Disconnect TNV circuit connectors before disconnecting power.
Use only the attached telephone cord (Listee’s No. E66597, Part No.
127A9002).
CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger (e.g., 24
AWG) UL Listed or CSA Certified Telecommunication Line Cord
IMPORTANT SAFETY INSTRUCTIONS - When using your telephone
equipment, basic safety precautions should always be followed to reduce
the risk of fire, electric shock and injury to persons, including the follwing:
1. Do not use this product near water for example, near a bathtub,
washbowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not
dispose of batteries in a fire. They may explode. Check with local codes
for possible special disposal instructions.
SAVE THESE INSTRUCTONS"
7 WARNING
The exclamation point within an equilateral triangle followed by the
word "Warning" is intended to alert the user to the possibility that a
disregard for the warning may result in fatal hazards or critical injuries.
% Be sure to focus your att ention on the Warning headings when reading
the user manual for the copier.
7 CAUTION
The exclamation point within an equilateral triangle followed by the
word "Caution" is intended to alert the user to the possibility that a
disregard for the caution may result in minor injuries or in physical
damage.
% Be sure to focus your att ention on the Caution headings when reading
the user manual for the copier.
