Internet faxing

5-10 FK-506

– If "E-MAIL" was selected in step 5, type in part of the registered

email address.

– A maximum of 10 characters can be entered.

7 Press the [,] or [+] key until the desired destination is selected, and

then press the [)] key.

– To recall the e-mail address of the selected destination and return

to the fax number input screen, press the [OK] key.

– If "NAME" was selected in step 5, select the registration name (AAA

TOKYO).

LDAP SEARCH (E-MAIL)

:TO

LDAP SEARCH (NAME)

TOKYO

AAA TOKYO

tokyo01
